Technics SX-KN7000P User Manual

7.6. Removing the LCD, CPL, CPC, CPR, ROT and INV
printed circuit boards
- Remove the control panel (see step “Removing the control panel, power SW panel,
SD panel, net panel and keyboard unit ”).
- Remove the control panel lid holding screws ( 10pcs.)as shown in Fig.10 .
19

Technics SX-KN7000P Specifications

General

Brand	Technics
Model	SX-KN7000P
Category	Electronic Keyboard
Language	English
