Technics SX-KN7000P User Manual

7.7. Removing the SD and SDSW printed circuit boards
- Remove the SD panel (see step “Removing the control panel, power SW panel, SD
panel, net panel and keyboard unit ”).
SD P.C.B.
- Remove the SD P.C.B. mounting screws ( 2pcs.) as shown in Fig.11 .
SDSW P.C.B.
21
