14. Printed Circuit Board
15. Block Diagram
16. Wiring Connection Diagram
17. Replacement Parts List
Notes:
*Important safety notice:
Components identified by mark have special characteristics important for safety.
Funrthermore, special parts which have purposes of fire-retardant (resistors), high-
quality sound (capacitors),low-noise(resistors), etc. are used.
When replacing any of components, be sure to use only manufacture’s specified parts
shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution statements.
*ACHTUNG:Die lasereinheit nicht zerlegen.Die lasereinheit darf nur gegen einc vom
hersteller spezifizierte einheit ausgetauscht werden.
*Capacity values are in microfarads (uF) unless specified otherwise, P=Pico-farads
(pF) F=Farads (F)
