*Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=
1,000K (OHM)
*The marking <RTL> indicates that the Retention Time is limited for this item. After the
discontinuation of this assembly in production, it will no longer be available.
*Since SW consists of buttons and P.C.B.’s, we do not supply it as an individual part
(refer to “Manual Keyboard Parts and Control Panel Parts Location ”.).
*[SPC] in Remarks columns parts that are supplied by SPC..
*“<IA>”-“<IG>”, marks in Remarks indicate languages of instruction manuals. [<IA> :
English, <IB> : French, <IC> : Germany, <ID> :Spanish, <IE> : Danish, <IF> :
Netherlands, <IG> : Italian, ]
Ref. No. Part No. Part Name & Description
Pcs
Remarks
1 QAQG102AA TOP CASE UNIT 1 P
1 QAQG102AB TOP CASE UNIT 1 EXCEP P
2 QMGG071AA TOP CASE CUSHION 7
3 QYKG326BA NET PANEL ASSY 1
4 XTW3+10Q SCREW 79
5 QYAG3009AB ASSEMBLED MUSIC RACK 1
6 RFKJXKN7000E BOTTOM CASE ASS'Y 1
6 RFKJXKN7000P BOTTOM CASE ASS'Y 1
7 SHGG3130A FOOT 4
8 QLZG022A CORE 3
9 QLZG017A CORE B 7
10 XTW3+14Q SCREW 4
11 K2AA2G000003 AC IN COVER 1 EXCEPT P PC
11 K2AB2G000003 AC IN COVER 1 P PC
12 XYN4+F20 SCREW 4 P PC
12 XYN4+F25 SCREW 4 EXCEPT P PC
13 XTW3+16JFZ SCREW 21
14 QMAG0292AA MAIN LID 1
15 QMRG2061AAK INSULATION SHEET 1 EXCEPT GM GU GT
15 QMRG2063AAK INSULATION SHEET 1 GM GU GT
16 QMRG2120AA ACP COVER 1
17 QQLG241AA CAUTION LABEL 1 P PC
17 QQLG251AA CAUTION LABEL 1 EB
18 QQLG253AA FAJ JACK LABEL 1
19 QQLG254AA MAIN JACK LABEL 1
20 XTV3+10G-M SCREW 14
21 XYE3+FJ10 SCREW 30
22 QLZG025A CORE 1
23 QLZG026A CORE 1
24 QMRG5300AA BBD SHEET 7
25 QSCG138A SHIELD SHEET 1
26 XTW3+10TFZ SCREW 22
27 XTV3+12G SCREW 2
28 SBCG110B POWER BUTTON 1
29 QGPG0166AA P.SW PANEL 1
30 QMRG2123AA P.SW COVER 1
31 QGPG0163AA CONTROL PANEL 1 P
31 QGPG0163AB CONTROL PANEL 1 EXCEPT P
32 QGUG1440AD1K BUTTON 1
47
