Technics SX-KN7000P User Manual

Ref. No. Part No. Part Name & Description
Pcs
Remarks
CN508 SJPG1320A CONNECTOR 1
CN641 SJPG7JS030A CONNECTOR 1
D501-07 RVD1SS133TA DIODE 7 B0AACK000004
D509 10 AK03WK DIODE 2 B0JAMD000005
D511 MA4150-M DIODE 1 MAZ41500M
D512 RVD1SS133TA DIODE 1 B0AACK000004
D641 MA4082-MTA DIODE 1 MAZ40820MF
D642 MA4033M DIODE 1 MAZ40330M
D643 MAZ40560MF DIODE 1
D644,45 ERA1502V5 DIODE 2 B0EAKM000061
D646-49 SVDS3V40 DIODE 4 B0EAKM000066
D650,51 MAZ40560MF DIODE 2
D654,55 AK03WK DIODE 2 B0JAMD000005
D656 MA2051LF DIODE 1 MAZ2051000LF
D657 MA2062LF DIODE 1 MAZ2062000LF
D658 AK03WK DIODE 1 B0JAMD000005
FP501,02 K5G202AA0003 FUSE 2
FP503 K5G302AA0003 FUSE 1
FP504,05 K5G3113A0001 FUSE 2
FP641 K5G202AA0003 FUSE 1
FP642,43 K5G402AA0003 FUSE 2
IC501-14 NJM4558L IC 14
IC641 AN6913 IC 1 AN6913-NT
IC643 KIA7915PI IC 1 C0CABLG00006
IC644 KIA7815PI IC 1 C0CAALG00016
IC701 PC900V IC 1 B3PAE0000002
JK501 QJJG010AA JACK HEADPHONE 1 1
JK502-09 QJJG019AA JACK 8
JK709 SJSG1390A JACK 1 K1CB108B0027
JP502 RWDJ06-150 JUMPER 1
L501-04 QLQGT3T131LA COIL 4
L505-08 QLBG005A COIL 4
L509 QLQGT3T131LA COIL 1
L510-12 QLQGT1D600LA COIL 3
L643-49 QLBG005A COIL 7
L650,51 G0C121Z00001 COIL 2
Q501 2SC1815TPE2 TRANSISTOR 1 B1AACF000023
Q502,03 2SJ498CDTA TRANSISTOR 2
Q504 2SD592AR TRANSISTOR 1 2SD0592AR
Q505 2SB621A-R TRANSISTOR 1 2SB0621AH
Q506 2SD592AR TRANSISTOR 1 2SD0592AR
Q507 2SB621A-R TRANSISTOR 1 2SB0621AH
Q508 SLA5007 TRANSISTOR 1 B1MADFC00001
Q509 2SJ425 TRANSISTOR 1 B1DCFG000001
Q510 2SK1188 TRANSISTOR 1 B1DAKG000001
Q511 DTC114YSA TRANSISTOR 1
Q512 2SA1015TPE2 TRANSISTOR 1 B1ACCF000016
Q513 2SC1815TPE2 TRANSISTOR 1 B1AACF000023
Q514 2SA1015TPE2 TRANSISTOR 1 B1ACCF000016
Q515,16 2SC1815TPE2 TRANSISTOR 2 B1AACF000023
Q641 2SA1643LF645 TRANSISTOR 1 B1BCED000002
Q642 2SC1815TPE2 TRANSISTOR 1 B1AACF000023
Q643 2SA1643LF645 TRANSISTOR 1 B1BCED000002
