Technics SX-KN7000P User Manual

Ref. No. Part No. Part Name & Description
Pcs
Remarks
X1101 EFOEC4004T3 4MHZ CERAMIC OSCILATOR 1
<CPC P.C.B.>
PCB12 SXPG238911B CPC PCB 1 <RTL>
CN1107 K1KA12C00012 CONNECTOR 1
CN1108 K1KA06C00008 CONNECTOR 1
D1195-02 RVD1SS133TA DIODE 8 B0AACK000004
D1203-06 LN282RPXVTX3 LED 4 LNJ282RKRX02
D1207-38 RVD1SS133TA DIODE 32 B0AACK000004
SW1155-94 EVQ21405R PUSH SWITCH 40 EVQ21405RJ
<CPR P.C.B.>
PCB13 SXPG239011A CPR PCB 1 <RTL>
C1003 ECA0JAK221XH 6V 220U 1
C1004 QCBG1H473ZFA 0.047U 1 F1E1H473A001
C1005 F1D1H102A012 0.001U 1
C1006 ECBT1H333KB5 0.033U 1 F1D1H333A012
C1007 ECA0JAK470XH 6V 47U 1
C1008 QCBG1H473ZFA 0.047U 1 F1E1H473A001
C1009 F1D1H102A012 0.001U 1
C1010 QCBG1H473ZFA 0.047U 1 F1E1H473A001
C1011 ECA0JAK221XH 6V 220U 1
C1012-14 QCBG1H473ZFA 0.047U 3 F1E1H473A001
CN1001 K1KA07C00007 CONNECTOR 1
CN1002 K1KA04B00032 CONNECTOR 1
CN1003 SJPG2JS080A CONNECTOR 1
D1001-08 RVD1SS133TA DIODE 8 B0AACK000004
D1009 LN382GPXVTX3 LED 1 LNJ382GKGX02
D1010 RVD1SS133TA DIODE 1 B0AACK000004
D1011,12 LN382GPXVTX3 LED 2 LNJ382GKGX02
D1013,14 LN282RPXVTX3 LED 2 LNJ282RKRX02
D1015-22 RVD1SS133TA DIODE 8 B0AACK000004
D1023-26 LN382GPXVTX3 LED 4 LNJ382GKGX02
D1027,28 LN282RPXVTX3 LED 2 LNJ282RKRX02
D1029-35 RVD1SS133TA DIODE 7 B0AACK000004
D1037 LN382GPXVTX3 LED 1 LNJ382GKGX02
D1039-42 LN282RPXVTX3 LED 4 LNJ282RKRX02
D1043-50 RVD1SS133TA DIODE 8 B0AACK000004
D1051 B3ABA0000397 DIODE 1
D1052-56 LN282RPXVTX3 LED 5 LNJ282RKRX02
D1057-64 RVD1SS133TA DIODE 8 B0AACK000004
D1065 B3ABA0000397 DIODE 1
D1066 LN382GPXVTX3 LED 1 LNJ382GKGX02
D1067-70 LN282RPXVTX3 LED 4 LNJ282RKRX02
D1071-78 RVD1SS133TA DIODE 8 B0AACK000004
D1079,80 B3ABA0000397 DIODE 2
D1081-84 LN282RPXVTX3 LED 4 LNJ282RKRX02
D1085-92 RVD1SS133TA DIODE 8 B0AACK000004
D1093,94 B3ABA0000397 DIODE 2
D1095-98 LN282RPXVTX3 LED 4 LNJ282RKRX02
D1099,00 RVD1SS133TA DIODE 2 B0AACK000004
D1101 RVD1SS133TA DIODE 1 B0AACK000004
72
