Technics SX-PX552 Service Manual

Ref. No. Part No. Part Name & Description Pcs Remarks
D232-42 LN282RPXVTX2 LED 11 CPR
D244-46 LN282RPXVTX2 LED 3 CPR
D256-59 LN282RPXVTX2 LED 4 CPL
D265-67 LN282RPXVTX2 LED 3 CPL
D280-83 LN282RPXVTX2 LED 4 CPL
D288 LN282RPXVTX2 LED 1 CPL
D291 LN282RPXVTX2 LED 1 CPL
F1 XBA1C40NU100 FUSE,4A 1
FJASP(P,PC,PY)
F1 XBA2C16TB0 FUSE,T1.6A 1
FJASP(X,XS,XD,XT,XA)
F2 XBA2C10TB0 FUSE,T1.0A 1
FJASP(X,XS,XT,XD,XA)
F3 XBA2C10TB0 FUSE,T1.0A 1
FJASP(EX,EZ,EG,EB,GN)
F3 XBA2C10TB0 FUSE,T1.0A 1
FJASP(X,XS,XD,XT,XA)
F4 XBA2C16TB0 FUSE,T1.6A 1
FJASP(EX,EZ,EG,EB,GN)
F4 XBA2C16TB0 FUSE,T1.6A 1
FJASP(X,XS,XD,XT,XA)
F4 XBA1C20NU100 FUSE,2A 1
FJASP(P,PC,PY)
F5 XBA1C20NU100 FUSE,2A 1
FJASP(P,PC,PY)
F5 XBA2C16TB0 FUSE,T1.6A 1
FJASP(EX,EZ,EG,EB,GN)
F5 XBA2C16TB0 FUSE,T1.6A 1
FJASP(X,XS,XD,XT,XA)
IC1 HD74LS138P IC 1 MKB1
IC1 KIA7815PI IC 1
FJASP
IC1 M37471M2196S IC 1 CPL
IC1 TMP95C061BF IC 1 MAIN
IC2 D74HC139GSE2 IC 1 MAIN
IC2 HD74LS07P IC 1 CPL
IC2 HD74LS138P IC 1 MKB2
IC2 KIA7915PI IC 1
FJASP
IC3 HD74LS07P IC 1 CPL
IC3 HD74LS138P IC 1 MKB2
IC3 M5218AL IC 1 FJASP
IC3 M5M34051FPE2 IC 1 MAIN
IC4 M5218AL IC 1 FJASP
IC4 T7WU04FTE12L IC 1 MAIN
IC5 M5218AL IC 1 FJASP
IC5 T7WU04FTE12L IC 1 MAIN
IC6 M5218AL IC 1 FJASP
IC6 QSIGX3C04005 IC 1 MAIN
IC6 SQTG9011A IC 1 MAIN
IC6 X27C4096DC10 IC 1 MAIN
IC7,C8 M5218AL IC 2 FJASP
IC8 M5256DFP70LL IC 1 MAIN
IC9 M5218AL IC 1 FJASP
IC9 M5256DFP70LL IC 1 MAIN
IC10 D97315GD201 IC 1 MAIN
IC10 M5218AL IC 1 FJASP
IC11 LH5P832N-10 IC 1 MAIN
IC11 M5218AL IC 1 FJASP
IC12 QCPL-260L IC 1 FJASP
IC12 QSIGX3C64001 IC 1 MAIN
IC14 TC7W08FTE12L IC 1 MAIN
IC15 TC7W04FTE12L IC 1 MAIN
IC21 PCM1734EA-E2 IC 1 MAIN
