Technics SX-PX552 Service Manual

9.4.2. Assembly
(Step1)
Insert the front part of the key into the chassis.
(Step2)
Insert the plate spring into the hammer notch (refer to [Fig. 5]).
(Step3)
While slowly lowering the key into the chassis, insert the plate spring into the notch at the rear
of the key (refer to [Fig. 5]).
(Step4)
Carefully insert the key into the opening in the chassis and slide the key towards the rear to lock
it in place (refer to [Fig. 5]).
[Fig. 5]
9.5. Disassembly of the pedal assembly
(Step1)
Remove the pedal assembly from the pedal box.
(Step2)
Disassemble the pedal assembly (refer to [Fig. 6]).
[Fig. 6]
