9.4. Disassembly and assembly of key(s)
- Follow the (Step1)-(Step3) of item 9.1.
- Follow the (Step1)-(Step3) of item 9.2.
- Follow the (Step1) of item 9.3.
9.4.1. Disassembly
(Step1)
Insert the thin solid board between white key and black key, push the claw (refer to [Fig. 4]).
(Step2)
While pressing slightly the front of the key, push the rear of the key forward to disengage the
key claw from the chassis (refer to [Fig. 4]).
(Step3)
Lift the key and remove it.
[Fig. 4]
8
