Technics SX-PX552 Service Manual

Ref. No. Part No. Part Name & Description Pcs Remarks
T1 QTPG1M025A POWER TRANSFORMER 1
EX,EB,EZ,EG,X,GN,XS,XT
T1 QTPG1M025A POWER TRANSFORMER 1
XD,XA
VR2 QRVG25P01B53 V.R.,VOLUME 1
W1 QJLG013AA PEDAL CORD 1
W2 QEXGST16060B WIRE WITH CONNECTOR 1
W3 QEXGVH03105B WIRE WITH CONNECTOR 1
W4 QEXGSS16022C WIRE WITH CONNECTOR 1
W5 QEXGSS05028A WIRE WITH CONNECTOR 1
W6 QEXGSS06030B WIRE WITH CONNECTOR 1
W7 QEXGSS07010A WIRE WITH CONNECTOR 1
W8 QEXGSS12010A WIRE WITH CONNECTOR 1
W9 QEXGSS10015A WIRE WITH CONNECTOR 1
W10 QEXGSS06105A WIRE WITH CONNECTOR 1
W11 QEXGVH02055C WIRE WITH CONNECTOR 1
W12 QEXGVH02040B WIRE WITH CONNECTOR 1
X1 EFOMC4004T5 OSCILLATOR 1 CPL
X1 QSXG2F2400A 24MHZ CERAMIC OSCILLATOR 1 MAIN
X2 QSXG2FR614DA 614KHZ CERAMIC OSCILLATOR 1 MAIN
X3 QSXG2F0100DA 1MHZ CERAMIC OSCILLATOR 1 MAIN
X4 QSXG1A1128A 11.28MHZ CERAMIC OSCILLAT 1 MAIN
Z1-Z9 EXBV8V101J
100 ×4
9 MAIN
Z11 EXBV8V103J
10K ×4
1 MAIN
Z12-21 EXBV8V471J
470 ×4
10 MAIN
Z32 EXBV8V331J
330 ×4
1 MAIN
Z34-36 EXBS8V471J
470 ×4
3 MAIN
Z37,38 EXBV8V472J
4.7K ×4
2 MAIN
Z40 EXBV8V223J
22K ×4
1 MAIN
20. Cabinet Parts Location
39
