Technics SX-PX552 Service Manual

Ref. No. Part No. Part Name & Description Pcs Remarks
R93 ERDS2TJ331 1/4W 330 1 FJASP
R93 ERJ6GEYJ101V 1/10W 100 1 MAIN
R94 ERD2FCVG101 100 1
FJASP
R94 ERJ6GEY0R00V 1/10W 0 1 MAIN
R95 ERD2FCVJ4R7 4.7 1
FJASP
R95 ERJ6GEYJ471V 1/10W 470 1 MAIN
R96,97 ERJ6GEYJ331V 1/10W 330 2 MAIN
R98 ERJ6GEYJ473V 1/10W 47K 1 MAIN
R99,00 ERDS2TJ681 1/4W 680 2 FJASP
R102 ERDS2TJ471 1/4W 470 1 FJASP
R102 ERJ6GEYJ123V 1/10W 12K 1 MAIN
R104 ERDS2TJ471 1/4W 470 1 FJASP
R104 ERJ6GEYJ123V 1/10W 12K 1 MAIN
R106 ERDS2TJ471 1/4W 470 1 FJASP
R106,07 ERJ6GEYJ104V 1/10W 100K 2 MAIN
R110 ERDS2TJ151 1/4W 150 1 FJASP
R111 ERDS2TJ330 1/4W 33 1 FJASP
R111,12 ERJ6GEYJ103V 1/10W 10K 2 MAIN
R113 ERDS2TJ221 1/4W 220 1 FJASP
R113 ERJ6GEYJ471V 1/10W 470 1 MAIN
R114 ERDS2TJ331 1/4W 330 1 FJASP
R114 ERJ6GEYJ471V 1/10W 470 1 MAIN
R115 ERQ14AJ2R0 2 1
FJASP
R116 ERJ6GEYJ471V 1/10W 470 1 MAIN
R116 ERQ14AJ2R0 2 1
FJASP
R117,18 ERJ6GEYJ471V 1/10W 470 2 MAIN
R200,01 ERJ6GEY0R00V 1/10W 0 2 MAIN
R202 ERJ6GEYJ221V 1/10W 220 1 MAIN
R204 ERJ6GEY0R00V 1/10W 0 1 MAIN
S1 QSPG1010AA POWER SWITCH 1
S1-S3 QSTGT001AA SW 3 PKB
SP1,2 QASG14P02A
14CM,6
2
SW1 EVQ21507K SW 1 CPR
SW1 QSRGT005AA SW 1
FJASP
SW1 QSSGT014AA SW 1 COM
SW2 EVQ21507K SW 1 CPR
SW9,10 EVQ21507K SW 2 CPR
SW17,18 EVQ21507K SW 2 CPR
SW25,26 EVQ21507K SW 2 CPR
SW33,34 EVQ21507K SW 2 CPR
SW41,42 EVQ21507K SW 2 CPR
SW49 EVQ21507K SW 1 CPR
SW59,60 EVQ21507K SW 2 CPL
SW66-68 EVQ21507K SW 3 CPL
SW73-76 EVQ21507K SW 4 CPL
SW81 EVQ21507K SW 1 CPL
SW84 EVQ21507K SW 1 CPL
SW89 EVQ21507K SW 1 CPL
T1 QTPG1M022A POWER TRANSFORMER 1
P,PC,PY
38
