9.7.2. Removing CPL and CPR P.C.B.
- Follow the item 9.2.
- CPL P.C.B.
(Step1)
Pull the MAIN VOLUME knob (refer to [Fig. 9]).
(Step2)
Remove the CPL P.C.B. mounting screws ×3, ×1, ×1 and ×10 (refer to [Fig. 9]).
- CPR P.C.B.
(Step1)
Remove the CPR P.C.B. mounting screws ×1, ×1, ×3 and ×10 (refer to [Fig. 9]).
[Fig. 9]
10. Symptoms Which Appear to be Signs of Trouble
The following changes in performance may occur in the Technics Digital Ensemble but do not
12
