Technify Motors TAE 125-02-114 User Manual

AFM Supplement DA 40 D
Page 2-3
Issue 2
Revision -, Aug. 2015
.................................................Shell Spirax GSX 75W-80 GL-4
............................................................ Shell Spirax S6 ATF ZM
..........................................................Centurion Gearbox Oil N1
q) Maximum restart altitude: .........................................14000 ft
2.5 ENGINE INSTRUMENT MARKINGS
Engine instrument markings and their color code significance
are shown in the tables below:
 CAUTION: Use approved oil with exact designation
only!
 CAUTION: If the gearbox oil level is too low the reason
must be determined and the problem must
be corrected by authorized personnel.
Indi-cation
Red
arc/bar
=
lower
prohibited
range
Yellow
arc/bar
=
caution
range
Green
arc/bar
=
normal
operating
range
Yellow
arc/bar
=
caution
range
Red
arc/bar
=
upper
prohibited
range
RPM
[RPM]
-- -- 0-2300 --
above
2300
Oil
pressure
[bar]
below 1.2 1.2 to 2.2 2.3 to 5.1 5.2 to 6.5 above 6.5
Oil temp.
[°C]
below -32 -32 to 49 50 to 129 130 to 140 above 140
Coolant
temp.
[°C]
below -32 -32 to 59 60 to 100 101 to 105 above 105
Gearbox
temp.
[°C]
-- -- below 115 115 to 120 above 120
Load
[%]
-- -- 0 - 100 -- --
Fuel
temp.
[°C]
below -30 -30 to +4 +5 to 69 70 to 75 above 75
Ammeter
[A]
-- -- below 85 85 to 90 above 90
