PG 7
1. Cast iron pan support (trivet) incldes WOK trivet (not pictured)
2. Burner with removable cap, distributor x 4
3. Control panel
4. Grill door
5. Shelf
6. Oven tray
7. Oven door glass
8. Oven door
9. Splashback (1 supplied)
10. Grill element (inside compartment)
11. Grill tray wire rack insert (reversible to adjust height)
12. Fan
13. Oven burner cover plate
14. Oven burner
15. Rear adjustable anti slip feet (2)
16. Anti tilt floor bracket
17. Kick panel (stability bolt located behind kick panel)
18. Front adjustable anti slip feet (2)
8
9
10
11
4
12
14
16
15
17
18
13
5
6
7
3
1
2
PRODUCT DESCRIPTIONS
1. Hotplate Burner Control Knob
• Sets the hotplate cooking temperature.
2. Grill Indicator Light
• Comes on when grilling.
3. Grill Temperature Control Knob
• Adjusts grilling temperature.
4. The oven control knob
• Sets Oven temperature.
Description of Electric Cooker
Controls
Front Control Panels
1
3
2
4
