TechniSat DigitRadio 210 User Manual

10
AfterchangingonlythesmallDABortheFMlogoisdisplayedrightnexttothetime.
DAB mode
What is DAB?
DAB is a new digital format, through which you can hear crystal clear sound in CD
quality.DABBroadcastahigh-speeddatastreamintheradiochannel.Indierenceto
conventional analog radio DAB transmitts multiple channels on the same transmitter.
Thisiscalledensembleormultiplexes.Anensembleconsistsoftheradiostationas
well as several service components or data services, which are sent individually by the
radio stations. Learn e.g. under www.digitalradio.de or www.digitalradio.ch.
Data compression
Digital radio uses the of advantages of human hearing. The human ear does not
perceive sounds that are below a certain minimum level. Data which are under the
so-calledthresholdinquietcanbelteredout.Thisispossiblebecauseinadigital
data stream for each information unit, the corresponding relative volume is also saved
for other units. In addition in a sound signal, the quieter portions are overlapped by
the louder for a given threshold. All the sound information in a piece of music that are
belowtheso-calledhearingthresholdcanbelteredoutofthesignaltobetransmit-
ted. This leads to a reduction of the transmitted data stream, without any noticeable
dierenceinsoundtothelistener(MUSICAM)process.
Audio Stream
Audiostreamsarecontinuousdataows,MPEG1AudioLayer2framescontainand
thus represent acoustic information in digital radio. Thus, familiar radio programs can
be transferred and listen at the receiver side. For Digital radio the MUSICAM format
isused,whichprovidestwoMPEGcompliantPADs.ThisisreferredtoasPADdata
services.DigitalRadiobringsyounotonlyradiowitforadditionaldata.Theexcellent
Digitalradiodoesnotonlyoerperfectsoundqualitybutalsoadditionalinformation.
Thismayrelatetothecurrentprogram(egtitle,artist)ormightbeindependent(eg,
news,weather,tractips).
Automatic Search
Asdescribedintheinitialinstallationtheunitrestartsautomaticallyattherststart
to search for DAB programs. This automatic search can also be restarted manually
without having to revert to the factory setting.
>To open the menu, press Menu (8).
>Push Tune up/down (6) until you have reached the menu point Full Scan.

TechniSat DigitRadio 210 Specifications

Frequency Range

frequency_range_dab_dab_plus	174.928 - 239.200 MHz
frequency_range_fm	87.5-108 MHz

Audio

audio_output	1 W rms

Power Supply

power_supply_input_voltage	100-240 V AC
power_supply_input_frequency	50-60 Hz
power_supply_output_voltage	6 V DC
power_supply_output_current	500 mA

Weight and Dimensions

dimensions	205 mm x 120 mm x 55 mm
