TechniSat DigitRadio 210 User Manual

9
Initial use
Whenyouusethedeviceforthersttime,aswellasaftercallingthefactorysetting
and siwtching on again, the channel search for DAB radio stations starts automatically.
During scanning, the display shows the progress of information and the number of
radio stations found.
Aftercompletionofthestationsearch,therststationisdisplayedinalphanumeric
order and played back automatically.
Note :
If no stations are found, no signal could be received. In this case change the location of
the device and / or the position of the wire antenna and run the scan channels again.
Volume adjustment
>Rotatetoadjustvolume+/-(13)thedesiredvolume.
- clockwise ->louder
- counterclockwise -> lower
Select DAB-/UKW-Betrieb
>Push the button DAB/FM (5) to switch between DAB mode and FM mode. During
the change from one mode to the newly selected mode will appear below the big time.

TechniSat DigitRadio 210 Specifications

Frequency Range

frequency_range_dab_dab_plus	174.928 - 239.200 MHz
frequency_range_fm	87.5-108 MHz

Audio

audio_output	1 W rms

Power Supply

power_supply_input_voltage	100-240 V AC
power_supply_input_frequency	50-60 Hz
power_supply_output_voltage	6 V DC
power_supply_output_current	500 mA

Weight and Dimensions

dimensions	205 mm x 120 mm x 55 mm
