TechniSat TECHNIRADIO 5 IR User Manual

64
15 Technical data
Power supply DC 8V, 2A
WiFi 802.11 b/g/n.
WEP and WPA/WPA2 encryption
WiFi frequencies and transmission
capacity
2.412 ~ 2.472 GHz (802.11 b/g/n)
1.5 dB
Reception frequencies DAB: Band III, 174 MHz - 240 MHz
FM: 87.5 MHz - 108 MHz
Music output 2 x 5W RMS
Power consumption Operating (max): < 15 W
Standby: < 2 W
Operating ambient conditions 5~35 °C
Dimensions 270x114x188 mm
Weight 1.7 kg
Technical data for supplied power cable
Manufacturer TechniSat Digital GmbH, TechniPark,
D-54550 Daun/Eifel, Germany
Model number OBL-0802000E
Input voltage AC 100 - 240 V
Input AC frequency 50/60 Hz
Output voltage DC 8.0 V
Output current 2.0 A
Output capacity 16.0 W
Average eciency during operation 85.2 %
Eciency under low load (10%) 74.9 %
Power consumption under zero load 0.06 W
The dimensions are approximate values.

TechniSat TECHNIRADIO 5 IR Specifications

General

Radio type	Portable
Tuner type	Digital
DAB band range	174 - 240 MHz
Supported radio bands	DAB, UKW
Radio Data System (RDS)	Yes
RMS rated power	10 W
Number of built-in speakers	2
Display type	TFT
Display diagonal	2.4 \
Ethernet LAN	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs	1
Headphone connectivity	3.5 mm
Coloration	Monochromatic
Product color	Black
Volume control	Rotary
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, FRE, ITA, NOR, POL, SLV
Power source	AC/DC
AC input voltage	230 V
DC input voltage	8 V
AC input frequency	50 Hz
Battery capacity	2000 mAh
Storage temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package type	Box
Package depth	1500 mm
Package width	3530 mm
Package height	2400 mm
Package weight	2270 g

Weight and Dimensions

Depth	1140 mm
Width	270 mm
Height	1180 mm
Weight	1660 g
