21
The menu items in some menus have to be highlighted by moving sideways. This is done by pressing
the right/left arrow keys.
By pressing the up/down arrow keys, it is possible to move the highlight from line to line and to
move upwards and downwards page by page using the page up/down buttons.
You will see the so-called menu path in the uppermost line of the menu. This shows you the menu
you are currently in and the path you took to reach this menu. In the example shown, this is Main
menu > Settings > Picture settings. The menu path is also shown throughout the operating manual
and shows you how you can reach the respective menu with the settings described.
If the blue function key with Help is displayed on the bottom line on the screen, a Help page can be
displayed by pressing this button, and hidden by pressing it again.
7.3 Accepting settings / Exiting menus and functions
In some menus and functions the changes made must be accepted manually in order to save them
permanently. If this does not happen, the function or the values that existed before the change was made
will be reset automatically on exiting the menu.
If an Accept field or the green function key with Accept is displayed in the bottom line of the screen,
you can see that the changes made must be saved manually to be accepted.
> By highlighting Accept using the right/left arrow keys and confirming with the OK button, or by pressing
the green function key Accept, the changes are saved and you move back up to the next menu up.
Alternatively:
> Press the Back key.
You are now asked whether the changes made should be accepted.
> Use the right/left arrow keys to highlight Ye s or No and confirm using the OK button.
According to your selection the changes are now saved or rejected and you return to the next menu level up.
Alternatively:
> To exit the menu immediately, press the Menu button.
In this case the settings that need to be saved manually will be reset.
If the green function key with Accept is not displayed on the bottom line of the screen, the changes
are saved automatically on exiting the menu.

TechniSat TECHNISTAR K4 ISIO Specifications

General

Product color	Black
Supported video modes	576i, 576p, 720p, 1080i, 1080p
Audio formats supported	AC3
Video formats supported	AVC, MPEG1, MPEG2, MPEG4
HDMI	Yes
USB version	2.0
USB port type	USB Type-A
USB ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Tuner type	Digital
Demodulation	16-QAM, 32-QAM, 64-QAM
Audio decoders	Dolby Digital
Interactive TV	-
Frequency range	47 - 862 MHz
Number of tuners	4 tuner(s)
Channels quantity	4999 channels
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, HUN, ITA, LIT, POL, POR, RUS, SWE, TUR
Signal source	Cable, Ethernet (RJ-45), Satellite
Video resolutions	1920 x 1080 pixels
Digital signal format system	DVB-C
Display digits	4 digits
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	3.4 W
Power consumption (typical)	8.4 W
Reception	HD-TV, SD-TV, radio
Symbol rate	1.5 - 7.2 Mbaud
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	212 mm
Package width	396 mm
Package height	56 mm
Package weight	1170 g

Weight and Dimensions

Depth	135 mm
Width	280 mm
Height	38 mm
Weight	500 g
