TechniSat TECHNISTAR K4 ISIO User Manual

9
The following references (a b c etc.) refer to the illustration on page 8.
5.1 Mains power connection
The digital receiver should only be connected to the mains power supply once you have finished making all the
connections to the various other components. This will prevent damage to the digital receiver or other components.
a Once you have made all the other connections in accordance with the following sections, use the
power cable supplied to connect the receiver to 230 V/50-60 Hz mains power outlet.
5.2 Cable connection
5.2.1 Connecting the DVB receiver
b Connect the receiver cable input to the cable connection socket using a suitable coaxial cable.
5.2.2 Connecting the TV
c Connect the receiver cable output to the antenna input on the next device (TV, video/DVD recorder)
using a suitable coaxial cable.
5.3 Connecting to a TV
d Connect the receiver (HDMI output) and TV (HDMI input) using an HDMI cable.
If your television set is appropriately equipped, this will be switched to the HDMI input automatically
when the digital receiver is switched on.
Alternatively:
e Connect the receiver (SCART port TV) and TV (SCART port) using a SCART cable.
If your TV is appropriately equipped, this will be switched to AV mode automatically when the digital receiver
is switched on, and is thus switched to satellite mode. The signal type to your TV must also be adapted.
5.4 Hi-Fi / surround sound amplifier
To achieve the best possible sound quality, you can connect your digital receiver to a hi-fi / surround sound amplifier.
5.4.1 Digital
f If your amplifier has an appropriate electrical or optical input, connect the electrical or optical
DIGITAL AUDIO OUT socket to the electrical or optical input on your amplifier.
Depending on the signal provided by each broadcaster, sampling rates of 32, 44.1 and 48 kHz are
available. In addition, where broadcast, the Dolby Digital signal is also available on this output.

TechniSat TECHNISTAR K4 ISIO Specifications

General

Product color	Black
Supported video modes	576i, 576p, 720p, 1080i, 1080p
Audio formats supported	AC3
Video formats supported	AVC, MPEG1, MPEG2, MPEG4
HDMI	Yes
USB version	2.0
USB port type	USB Type-A
USB ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Tuner type	Digital
Demodulation	16-QAM, 32-QAM, 64-QAM
Audio decoders	Dolby Digital
Interactive TV	-
Frequency range	47 - 862 MHz
Number of tuners	4 tuner(s)
Channels quantity	4999 channels
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, HUN, ITA, LIT, POL, POR, RUS, SWE, TUR
Signal source	Cable, Ethernet (RJ-45), Satellite
Video resolutions	1920 x 1080 pixels
Digital signal format system	DVB-C
Display digits	4 digits
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	3.4 W
Power consumption (typical)	8.4 W
Reception	HD-TV, SD-TV, radio
Symbol rate	1.5 - 7.2 Mbaud
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Package depth	212 mm
Package width	396 mm
Package height	56 mm
Package weight	1170 g

Weight and Dimensions

Depth	135 mm
Width	280 mm
Height	38 mm
Weight	500 g
