TechniSat TECHNISTAR S5 User Manual

5
EN
Rear
8 9 10 11 12 13 14
8 LNB port (DC 13/18V, max. 600mA)
9 Ethernet connection
10 USB port
11 HDMI output
12 A/V output (Video/Audio analogue)*
13 S/PDIF output (Audio Digital)
14 Power supply unit connection (DC 12V, 2A)
*For TechniSat- specific adapter set, article number 0000/3649
Front flap open (grip on side and open downwards):
Smart card
slot
CI/CI+ module
slot
Eject buon
CI/CI+ module
Insert the smart card with the gold contacts forwards and facing downwards
into the smart card slot.
To eject an inserted CI/CI+ module, press the eject buon and remove the
module.

TechniSat TECHNISTAR S5 Specifications

General

Brand	TechniSat
Model	TECHNISTAR S5
Category	Receiver
Language	English
