Technische Alternative ESR 31 Series User Manual

50
EX
CS
EX
CS
Control output 0-10V/PWM COP
OFF/5V/0-10V/PWM
OFF
Output OP
--
Abs.value control AC
--
Desired value DVA
50°C
°C
Diff. control system DC
--
Desired value DVD
10 K
K
Event control syst. EC
--
Desired value TVE
60°C
°C
Desired value DVE
110°C
°C
Proportional part PRO
5
Integral part INT
0
Differential part DIF
0
Min. analogue stage MIN
0
Max. analogue stage
MAX
100
Function check F CHCK
ON/OFF
OFF
Heat quantity counter HQC
ON/OFF
OFF
Flow sensor SSL
S1
Return sensor SRL
S2
Vol.flow encoder VSG
--
Litres pro pulse LPP
0,5
Volume flow V
50 l/h
l/h
Share of antifreeze SA
0%
%
External sensors EXT DL
External value E1
--
External value E2
--
External value E3
--
External value E4
--
External value E5
--
External value E6
--
