Technische Alternative UVR61-3 User Manual

117
EX CS EX CS
Sensor type SENSOR
Sensor S1 PT1000 Average determ. AV1 1,0 s s
Sensor S2 PT1000 Average determ. AV2 1,0 s s
Sensor S3 PT1000 Average determ. AV3 1,0 s s
Sensor S4 PT1000 Average determ. AV4 1,0 s s
Sensor S5 PT1000 Average determ. AV5 1,0 s s
Sensor S6 PT1000 Average determ. AV6 1,0 s s
S6 = VSG  Litres per
pulse LPP
0.5
System protection function SYS PF
Collector excess temperature CET 1 Frost protection function FROST 1
ON/OFF ON ON/OFF OFF
Collector sensor COLL 1 Collector sensor COLL 1
Outputs OP 1 Outputs OP 1
Switch-off temp. max 130°C °C Switch-on temp. min 2°C °C
Switch-on temp. max 110°C °C Switch-off temp. min 4°C °C
Collector excess temperature CET 2 Frost protection function FROST 2
ON/OFF OFF ON/OFF OFF
Collector sensor COLL 2 Collector sensor COLL 2
Outputs OP 2 Outputs OP 2
Switch-off temp. max 130°C °C Switch-on temp. min 2°C °C
Switch-on temp. max 110°C °C Switch-off temp. min 4°C °C
Collector cooling function COOLF Anti-blocking protection ASC
ONN/OFF OFF ON/OFF OFF
Sensor SENS 1 Interval time DAYS 7
Nominal value DV 80°C °C Starting time  15.00
Switch-on time  22.00 Pump run time PRT 15s s
Switch-off time  06.00 Outputs OP 1
Outputs OP 1
Speed stage SPS 30
Start function STARTF
Start function 1 STF1 Start function 2 STF2
ON/OFF OFF ON/OFF OFF
Collector sensor COLL 1 Collector sensor COLL 2
Radiation sensor GBS -- Radiation sensor GBS --
Radiation thresh. RTH 150 W W Radiation thresh. RTH 150 W W
Outputs OP 1 Outputs OP 2
Rinse outputs OPS 1 Rinse outputs OPS 2
Pump run time PRT 15 s s Pump run time PRT 15 s s
Interval time INT 20 min min Interval time INT 20 min min
