Solar priority PRIOR
Radiation sensor GBS -- Radiation value RTH 150 W W
Rinse outputs OPS 1 Waiting time WTL 5 min min
Pump run time PRT 20 min min
After-running time ART
AT 1 0 s s AT 2 0 s s
AT 3 0 s s
Pump speed control PSC
Abs.value control. AC -- Desired value DVA 50°C °C
Differential control DC -- Desired value DVD 10 K K
Event control EC -- Threshold value TVE 60°C °C
Desired value DVE 130°C °C
Waveform
WAVEP
Proportional part PRO 5 Integral part INT 0
Differential part DIF 0
Minimum speed MIN 0 Maximum speed MAX 30
Delay time ALV 0
Control output 0-10V / PWM COP
Control output COP 1
OFF/5V/0-10V/PWM/
STAT N/STAT I
OFF Outputs OP --
Abs.value control. AC -- Desired value DVA 50°C °C
Differential control DC -- Desired value DVD 10 K K
Event control EC -- Threshold value TVE 60°C °C
Desired value DVE 130°C °C
Proportional part PRO 5 Integral part INT 0
Differential part DIF 0 Output mode 0-100
Min. analog stage MIN 0 Max. analog stage MAX 100
Delay time ALV 0
Control output COP 2
OFF/5V/0-10V/PWM/
STAT N/STAT I
OFF Outputs OP --
Abs.value control. AC -- Desired value DVA 50°C °C
Differential control DC -- Desired value DVD 10 K K
Event control EC -- Threshold value TVE 60°C °C
Desired value DVE 130°C °C
Proportional part PRO 5 Integral part INT 0
Differential part DIF 0 Output mode 0-100
Min. analog stage MIN 0 Max. analog stage MAX 100
Delay time ALV 0
Function control F CONT
ON/OFF OFF Circulation control
CIRC --/A/M
--
Circulation O1 CC1 -- Circulation O2 CC2 --
Circulation O3 CC3 --
