SB series User’s manual
11
RX bar
TX bar
TX bar
RX bar
5 MECHANICAL ASSEMBLY
Use the appropriate brackets provided to complete the mechanical
assembly.
The securing brackets for the bars slide in the container’s grooves so that
their ends can be placed at an equal distance from each other.
OK
NONO
SB series User’s manual
12
6 CONNECTIONS
6.1 REFERENCES FOR CABLES:
The test connection must always be executed with a N.C. button or
connected to an automatic device, such as a PLC.
