51PLURIMA
G
F
Replacing the cable
Follow the steps indicated in the drawing to insert the lever cables.
Check that the cable is laid correctly in the grooves of all the pulleys.
Insert the nut (G) in the cable.
Insert the cable in the adjustment screw housing (F) and then tighten the
nut (G).
Tighten the adjustment screw (F) in the frame.
