62PLURIMA
M
M
J
K
L
H
Replacing the cable
Take the cable out of the arm, then out of pulley (J) and then out of pulley (K).
Take the cable out of the pulley group (H) and then from the pulley (L).
Loosen the two central pulleys (M) with an 8 mm T spanner and a 17 mm open-
ended spanner without removing them.
Loosen the pulley block on the crosspiece with a 17 mm adjustable spanner
and a 6 mm T spanner.
Take the cable out of the 3 pulleys.
