Technogym Selection Cable Jungle - Replacing the Cables - Side 3; Side 3 High and Low Pulley Cable Replacement

25
Cable Jungle
3
B
C
D
Replacing the cables
Side 3, high pulley and low pulley
The cable is secured with two identical connectors with screws (B), three for
each connector.
- Remove any accessories;
- raise rubber gaiter (A);
- unscrew the screws (B) and pull the cable out of connector (C);
- repeat for the other end of the cable;
- remove the whole cable from the equipment;
- insert the new cable (ensuring that it follows the same route as the original
cable, as shown in the illustration);
- insert rubber gaiter (A) and connector (C); then tighten the screws (B);
- lower the rubber gaiter (A);
- repeat for the other end of the cable.
