Technogym SKILLRUN UNITY 5000 - Network Requirements; Network Introduction; LAN Setup for Unity Freezing Prevention; Ethernet Cabled Network Specs

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 21 -
5. NETWORK REQUIREMENTS
5.1 INTRODUCTION
SKILLRUN UNITY 5000 /7000 (equipment tted with UNITY 3.0) support both wireless and wired
internet connection.
NOTE: In all situations, where possible, Technogym recommends connection via network
cable.
SKILLRUN TX 500 (equipment tted with TX10” interface) support a wireless internet connection.
In all cases, the network must be installed and congured by the customer before Technogym deliv-
ers the product, in accordance with the technical specications set out below.
5.2 FREEZING UNITY DUE TO A WRONG LAN
NETWORK SETUP (ONLY FOR SKILLRUN UNITY
5000 / 7000)
In case of Unity in a scenario with a LAN network, It is suggested to congure a dedicate LAN
network without external devices connected - such as Smart TV or other devices- that put in the
network a very high volume of broadcast packets and could generate randomly freezing on Unity.
There are two possibilities to avoid the issue:
1. Congure properly the switch to lter unexpected broadcast high volume tra󰀩c (in case of
external devices connected in the same LAN network of the equipment);
2. Avoid to connect external devices in the same LAN network of the equipment.
5.3 ETHERNET CABLED NETWORK (ONLY FOR
SKILLRUN UNITY 5000 / 7000)
_Category 5e/6 - UTP Ethernet cables with RJ45 patch;
_Switch with a number of ports greater than the number of equipment tted with UNITY 3.0 con-
nected.
5.4 WI-FI NETWORK REQUIREMENTS
_ Standard: IEEE 802.11 a/b/g/n at 5GHz or 2.4GHz;
_ Security Protocol: WEP, WPA/WPA2, open (free) network;
