C
Copyright Technolog Ltd. 2017. All rights reserved.
Information contained in this document subject to
change without prior notice.
Sheet 2 of 43
Technolog Limited,
Ravenstor Road,
Wirksworth,
DE4 4FY,
United Kingdom
T: +44 (0) 1629 823611
E: techsupport@technolog.com
www.technolog.com
DMR No.: 7504
2099PM9000 Rev. B
Contents
1 - Cover
2 - Contents
3 - Forward
4 - Considerations (Environment, Installation, Approvals)
5 - Precautions (Handling, Cleaning,Lithium batteries, Disposal / end of life)
6 - Dimensions
7 - Typical installation: Moulded wall bracket (p / no. 2099TT6400)
8 - Typical installation: Stainless steel wall bracket (p / no. 2099TT6500)
9 - Typical installation: Boundary box, meter pit, vault or similar.
10 - Standard connections: Overview
11 - Standard connections - Port 1: Local communications ('COMMs')
12 - Standard connections - Port 2: External power
13 - Standard connections - Port 3: Two channel input (analogue and / or digital) connection
20 - Standard connections - Port 3: Local communications ('COMMs')
21 - Standard connections - Port 4: Internal pressure sensor
22 - Standard connections - Port 4: External pressure sensor connection
23 - Standard connections - Port 4: Universal eight signal connection
28 - Standard connections - Port 4: Encoder connection
29 - Standard connections - Port 5: External antenna connection
30 - Standard connections - Port 6: Internal pressure sensor
31 - Standard connections - Port 6: External pressure sensor connection
32 - Standard connections - Port 6: Universal eight signal connection
33 - Standard connections - Port 6: Encoder connection
34 - Standard connections: Channel mapping
35 - Standard connections: Channel shadowing
36 - Unit identification
37 - Entering the enclosure
38 - SIM card replacement
39 - Internal battery pack replacement
40 - Universal 8 signal input (4-20mA) 'dip switch' setting options
42 - Refitting the enclosure lid
43 - Installation / maintenance: Local Wi-Fi communications
