TecMate Optimate 2 User Manual

2
Model: TM421
INPUT/ALIMENTATION/RED
100-240V 50-60Hz
0.23A@100Vac / 0.15A@240Vac
OUTPUT/SORTIE/SALIDA
12V 0.8A
READ INSTRUCTIONS & WARNING LABELS
LIRE LES INSTRUCTION ET ETIQUETTES
LEER LAS INSTRUCCIONES Y ETIQUETAS
BC
12V
2V
13.6V
14.4V
1 2 3 4
4 STEPS
2
2
#1
#2
#3
#4
LED #1 - AC POWER (100-240V)
LED #2 - Reverse polarity
LED #3 - Low Volt SAVE, CHARGE, OPTIMIZE
LED #4 - MAINTAIN (& TEST)
4x
 4.5mm (1/6")
L +20mm (+4/5")
2m (6ft) max.
2m (6ft) + 3 (1,8m (5ft)) = 3,8m (12ft) max.
+ 13 / 23 (4,6m (15ft) = 6,6m(21ft) max.
3 / 13 / 23
6ft
max.
MOUNTING NOTICE
NOTICE DE MONTAGE
NOTA PARA EL MONTAJE
NOTA DA MONTAGEM
WANDMONTIERUNG
MUURBEVESTIGING
NOTA DEL MONTAGGIO
VÄGGMONTERING
ИНСТРУКЦИЯ ПО МОНТАЖУ
Low Volt
Save
(from 2V)
OPTIMIZECHARGE
OptiMate
Maintenance
