4 PRODUCT DESCRIPTION
PAR DESCRIPTION
4.1 TECHNICAL SPECIFICATIONS
See “Technical Details”.
FIGURE 1 – Breaker
4 PRODUCT DESCRIPTION
PAR DESCRIPTION
4.2 DEVICE DESCRIPTION
A sample design has
been shown in the
following figure.
The delivered
hydraulic breaker can
thus deviate from
the figure
Inform your dealer or TECNA, if the Technical Details are not provided during the delivery.
1. Support for the quick-change
device
2. Locking pins
3. Tool
4. Retaining wedges
5. Hydraulic connection - OUT
6. Hydraulic connection - IN
OPERATING MANUAL - Hydraulic breakers T series
