6.7 CONNECTING THE HYDRAULIC BREAKER HYDRAULICALLY
FIGURE 9: Hydraulic connections – DESIGN 1
DAMAGE TO THE HYDRAULIC BREAKER!
Hydraulic lines and hoses, which are fitted under voltage, generate additional mechanical forces
during operation which reduces the service life of the hydraulic breaker and the support frame
hydraulic system.
»
Fit the lines and hoses without tensioning.
3. Connect all the connections and follow the support frame operating manual.
Pay attention to the different designs of the hydraulic connections of the hydraulic
breaker in the following figures.
