EV 10-50
43
Wireless hybrid arm sy em
Wireless hybrid arm sy em
Thermostat 01 4
Summer mode [#]
Thermostat 01 5
Hysteresis 22.0°_ System ok
Thermostat 01 5
Hysteresis
22.0°_ System ok
Thermostat 01 6
Anti-freeze temp.
Hysteresis 1
0.10°C
Thermostat 01 5
Hysteresis
Thermostat 01 6
Anti-freeze temp.
Anti-freeze temp. 1
+01.0°C
Thermostat 01 6
Anti-freeze temp.
22.0°_ System ok
Thermostat 01 7
Warn. high temp.
4
Summer mode
menu
The menu allows you to program the summer/winter mode of the thermostat.
Enable [#] or disable [ ]
the summer mode
Save and exit
Select the next menu
Access the Summer mode menu
Access the menu with the YES button.
Enable [#] summer mode with the YES button
or disable [ ] summer mode with the NO button.
Select the next menu with the arrow button or save
and exit by repeatedly pressing the EXIT button.
5
Hysteresis
menu
The menu allows you to program the temperature hysteresis threshold, i.e. the difference between the programmed
temperature and the boiler ignition temperature.
Access the Hysteresis menu
Access the menu with the YES button.
Select the hysteresis value with the arrow button.
Confi rm the value with the EXIT button.
Select the next menu with the arrow button or save
and exit by repeatedly pressing the EXIT button.
Save and exit
Access the menu
Select the hysteresis value:
+/-0.10°C, +/-0.15°C, +/-0.20°C
Confi rm the value
Select the next menu
6
Anti-freeze temp.
menu
The menu allows you to program the minimum water temperature threshold of the heating system.
Save and exit
Select the next menu
Confi rm the temperature
Access the menu
Select the anti-freeze temperature
Max 15°C min 1°C
Access the Anti-freeze temp. menu
Access the menu with the YES button.
Select the value of the Anti-freeze temperature with
the arrow button.
Confi rm the value with the EXIT button.
Select the next menu with the arrow button or save
and exit by repeatedly pressing the EXIT button
