TECO JSMA-PLC08AB - Page 33

33
Display Parameter
Parameter
Signal
Display Unit Explanation
Un-01
Actual Motor Speed rpm
Motor Speed is displayed in rpm.
Un-02
Actual Motor Torque %
It displays the torque as a percentage of the rated torue.
Ex: 20 are displayed. It means that the motor torque output is 20% of
rated torque.
Un-03
Regenerative load rate
%
Value for the processable regenerative power as 100% .
Displays regenerative power consumption in 10-s cycle.
Un-04
Accumulated load rate
%
Value for the rated torque as 100%.
Displays effective torque in 10-s cyle.
Un-05
Max load rate
% Max value of accumulated load rate
Un-06
Speed Command rpm
Speed command is displayed in rpm.
Un-07
Position Error Value pulse
Error between position command value and the actual position
feedback.
Un-08
Position Feed-back Value pulse
The accumulated number of pulses from the encoder.
Un-09
ExternalVoltage Command V
External analog voltage command value in volts.
Un-10
(Vdc Bus)Main Loop
Voltage
V
DC Bus voltage in Volts.
Un-11
External Spped Limit
Command Value
rpm
External speed limit value in rpm.
Un-12
External CCW Torque Limit
Command Value
%
Ex: Display 100. Means current external CCW torque limit command is
set to 100 %.
Un-13
External CW Torque
LimitCommand Value
%
Ex: Display 100. Mean
s current external CW toque limit command is set
to 100%.
Un-14
Motor feed back – Less
then 1 rotation pulse
value(Low Byte)
pulse
After power on, it displays the number of pulses for an incomplete
revolution of the motor as a Low Byte value.
Un-15
Motor feed back – Less
then 1 rotation pulse
value(High Byte)
pulse
After power on, it displays the number of pulses for an incomplete
revolution of the motor as a High Byte value.
Un-16
Motor feed back – Rotation
value (Low Byte)
rev After power on, it displays motor rotation number as a Low Byte
value.
Un-17
Motor feed back – Rotation
value (High Byte)
rev After power on, it displays motor rotation number as a High Byte
value.
Un-18
Pulse command – Less
then 1 rotation pulse
value(Low Byte)
pulse
After power on, it displays pulse command input for an incomplete
rotation. pulse value is a Low Byte value.
Un-19
Pulse command – Less
then 1 rotation pulse
value(High Byte)
pulse
After power on, it displays pulse command input for an incomplete
rotation. pulse value is a High Byte value.
Un-20
Pulse command – rotation
value(Low Byte)
rev
After power on, it displays pulse command input rotation number in
Low
Byte value.
Un-21
Pulse command – rotation
value(High Byte)
rev
After power on, it displays pulse command input rotation number in
High
Byte value.
