TECO JSMA-PLC08AB - Chapter 4 Parameter Function; Explanation of Parameter Groups; Parameter Display Table

32
Chapter 4 Parameter
4-1 Explanation of Parameter groups.
There are 9 groups of parameters as listed below.
4-2 Parameter Display Table
Diagnosis Parameter
Parameter Name & Function
Chapter
dn-01 Selected control mode
dn-02 Output terminal signal status.
dn-03 Input terminal signal status.
dn-04 Software version
dn-05 JOG mode operation
dn-06 Hold position.
dn-07 Auto offset adjustment of external analog command voltage.
dn-08 Servo model code.
dn-09 ASIC software version display
3-2-2
Alarm
Code
Description
Un-xx
Status Display Parameters.
dn-xx
Diagnostics Parameters.
AL-xx
Alarm Parameters
Cn-0xx
System Parameters
Tn1xx
Torque Control Parameters
Sn2xx
Speed Control Parameters
Pn3xx
Position Control Parameters
Pn4xx
Internal Position Control
Parameter
qn5xx
Quick Set-up Parameters
Hn6xx
Multi-function I/O parameters
Control Mode Code
Signal Control Mode
ALL
All Control Mode
Pi
Position Control Mode(Internal Positional Command )
Pe
Position Control Mode(External Puls Command)
S
Speed Control Mode
T
Torque Control Mode
Definition of Symbols.
Symbol Explanation
★
Parameter becomes effective after recycling the power.
◆
Parameter is Effective without pressing the Enter key.
●
Parameter is not effected by Cn029.
