Speed-Control Parameter
Address
Parameter Name & Function Default Unit
Setting
Range
RS232 RS485
Internal Speed Command 1
Sn201
In Speed control, input contacts SPD1 and SPD2 can be used to
select 3 sets of internal speed command, select for speed
command 1 contact status shows below:
Input Contact SPD2 Input Contact SPD1
0 1
Note: Input contacts status “1” (ON) and “0” (OFF)
Refer to 5
-6-1 to set high or low input logic levels.
100 rpm
-4500
│
4500
536H 0201H
Internal Speed Command 2
Sn202
In Speed control, input co
ntacts SPD1 and SPD2 can be used to
select 3 sets of internal speed command, select for speed
command 2 contact status shows below:
Input Contact SPD2 Input Contact SPD1
1 0
Note: Input contacts status “1” (ON) and “0” (OFF)
Refer to 5
-6-1 to set high or low input logic levels.
200 rpm
-4500
│
4500
537H 0202H
Internal Speed Command 3
Sn203
In Speed control, input contacts SPD1 and SPD2 can be used to
select 3 sets of internal speed command, select for speed
command 3 contact status shows below:
Input Contact SPD2 Input Contact SPD1
1 1
Note: Input contacts status “1” (ON) and “0” (OFF).
Refer to 5
-6-1 to set high or low input logic levels.
300 rpm
-4500
│
4500
538H 0203H
Zero Speed selection Enable or Disable the zero speed
preset parameter Sn215.
Setting Explanation
0 No Action. ( Sn215 zero preset is not effective).
Sn204
1 Set the preset value in Sn215 as zero speed.
0 X
0
│
1
529H 0204H
Speed command accel/decel smooth method.
Setting Explanation
0
By Step response
1
Smooth Acceleration/deceleration according to the cu
rve
defined by Sn206.
2 Linear accel/decel time constant .Defined by Sn207
Sn205
3 S curve for Acceleration/deceleration. Defined by Sn208.
0 X
0
│
3
52AH 0205H
