12
Figure 5 legend
Item
Description
1.
Connect one end of each LAN cable shield to the ring terminal and fasten with M3 screw
to the Challenger panel board’s LAN earth terminal.
2.
Connect the power terminals to a 16 Volt AC plug pack. Maximum current drawn by the
panel with no peripheral devices connected is approximately 200 mA.
3.
Connect the power earth terminal to the plug pack earth wire.
4.
Connect the + and – terminals to a 12 V sealed lead acid battery (7.6 Ah recommended),
not supplied.
Note: A battery must be connected in order to use internal or external siren speakers.
– Both 8 ohms and 12VDC
5.
Connect the + and – auxiliary power output terminals to devices that require 12 Volt DC
power, such as detectors. See “Auxiliary power terminals” on page 15.
6.
Connect the D+ and D– terminals to the RS-485 data cable for LAN 1.
If the + and – terminals are used, consider the current draw as part of the auxiliary power
output. See “Auxiliary power terminals” on page 15.
7.
Input and common terminals for panel tamper switch (supplied). Short circuit for sealed,
open circuit for unsealed. Must be sealed if not used. Can only be used with normally
closed contacts such as the panel tamper switches.
8.
Connect the S+ and S– terminals to an external 8  siren speaker or external device that
requires 12 Volt DC power. If an external device is not used, connect the S+ and S–
terminals to a 1K 1/4 watt resistor (supplied).
The maximum current draw for the external 8  siren and the strobe is 700 mA.
Current draw for external 12 VDC device for DC Volt mode is maximum 700mA and for
Standard Siren Mode is 2 8 ohms speakers.
The internal and external siren speaker outputs are relay 16 and are mapped to event
flag 1.
9.
Connect the S+ and S– terminals to an internal 8  siren speaker or internal device that
requires 12 Volt DC power.
If an internal device is used, consider the current draw as part of the auxiliary power
output. See “Auxiliary power terminals” on page 15.
10.
Connect the + and – terminals to the strobe. The maximum current draw for the external
8  siren and the strobe is 700 mA. The strobe output is relay 2 and is mapped to event
flag 2.
11.
Connect the D+ and D– terminals to the RS-485 data cable for LAN 2 (if required).
If the + and – terminals are used, consider the current draw as part of the auxiliary power
output. See “Auxiliary power terminals” on page 15.
12.
Zone input terminals. See “Zone inputs” on page 16.
13.
RJ-12 socket to telephone system (dialler). See “Telephone connection” on page 20.
14.
Slot for SD card.
15.
100BT LED on when Ethernet speed is 100 Mbps.
16.
Ethernet port.
17.
Link Active LED flashes to indicate Ethernet activity.
18.
J18 USB port for “Type A Male to Type B Mini Male” or “Type A Male to Type B Micro
Male” cable (depending on board revision number).
