32
14. On the Definition tab, tick the Enable checkbox.
15. On the Communication tab, select UDP/IP from the drop-down list for the
Type field. Enter the Challenger panel’s IP address and IP port number (for
example 3001) in the IP address and Port fields, respectively.
16. Save the panel record by clicking the Save button in the form’s toolbar.
17. Click the Connections button on the ribbon to view the list of panel
connections. The new entry for the panel in the connections list should indicate
that the panel is enabled and online.
Example 3: Programming an UltraSync connection
The steps required to connect management software to a ChallengerPlus panel
via UltraSync are:
Get the ChallengerPlus panel’s serial number
Set up communications hardware on ChallengerPlus panel
Configure UltraSync on ChallengerPlus panel
Connect to ChallengerPlus panel from CTPlus
