Midi Operation
The controller will only respond to MIDI commands on the
MIDI channel that it is assigned to. All MIDI control is per-
formed using Note on commands. All other MIDI instruc-
tions are ignored. To stop a chase, send the blackout note.
Setting MIDI IN
1. While holding down the RECORD button simul-
taneously tap Flash button #1 three times. The
display reads MIDI CHANNEL IN to indicate chan-
nel setup is available.
2. Select the MIDI control channel (1-16) by tap-
ping Flash buttons 1-16. The relevant channel
LED lights indicating MIDI IN channel is set.
3. While holding down RECORD, tap the REC EXIT
button to exit MIDI SETTING.
MIDI note Function Turn ON/OFF
22-69
70-117
Trigger scenes 1-48 (100%)
118
119
FULL ON
DARK (momentary blackout)
120 HOLD
121 Turn on or o AUDIO
122 MODE: Chase-Scene
123 Mode: 1-12a 1-12b
124 Mode: 1-24a
125 Step
126
127
Blackout
Channel page (1-24, 25-48)
Observations
- This is the Channel that the controller will re-
ceive MIDI note commands.
Setting MIDI OUT
1. While holding down the RECORD button simul-
taneously tap Flash button #2 three times. The
display reads MIDI CHANNEL OUT to indicate chan-
nel setup is available.
2. Select the MIDI control channel (1-16) by tap-
ping Flash buttons 1-16. The relevant channel
LED lights indicating MIDI OUT channel is set.
3. While holding down RECORD, tap the REC EXIT
button to exit MIDI SETTING.
Observations
- This is the Channel that the controller will trans-
mit MIDI note commands.
Receiving MIDI File Dump
1. While holding down the RECORD button simul-
taneously tap Flash button #3 (3) times. The dis
play reads MIDI FILEDUMP RECVING 000% when
the device is in the corrrect mode.
2. While holding down RECORD, tap the REC EXIT
button to exit MIDI setting.
Observations:
- This is the process of copying your entire show
to another Navigator 24XL. This will not work with
any other device.
- This process can take several minutes to com-
plete. The controller will automatically begin send-
ing the FILE DUMP once the mode has been se-
lected. Therefore, be sure that the other device
has previously been setup to receive the transfer.
- During FILE DUMP, all other operatioons will
cease to function.
- If errors or power failure occurs, FILE DUMP will
be interrupted and stop.
