TECshow NAVIGATOR 24 XL User Manual

NAVIGATOR 24XL
P.
2
1. Overview
Navigator 24 XL is a DMX dimmer controller with 48 chan-
nels distributed in 4 pages with 12 scenes each, where you
can arrange up to 48,000 program steps. With 24 faders (48
ch. in 2 pages) of simultaneous playback in the size of a 24
channels console, this controller allows the user to save
space making it an ideal solution for mobile applications.
Having MIDI and direct audio inputs plus an incorporated
microphone, Navigator 24 XL is ideal for working side by
side with music. Apart from that it also has a two scene
crossfader that helps making so transitions.
Specifications
Interface
• LCD Display
• Manual control of 48 channels -
• 24 faders distributed in two pages
• 2 programmable auxiliary buttons
• 24 buttons
• Tap Sync button for chase/fade of Override
• Full On button - 100% intensity in all channels
• Black Out button - 0% intensity in all channels
• Features
• 48 DMX channels
• 48 programmable scenes
• 96,000 programmable steps
• Adjustable chases and fade time
• Re-assignable channels
• Speed control
• Stackable scenes for simultaneous or sequen-
tial playback
• Manual override
• DMX polarity selector
• Beat, tap sync, auto run and midi in/out activ.
Connectors
• 1 XLR-3 DMX output
• 1 XLR-5 DMX output
• 3 DIN connectors: MIDI (In/Thru/Out)
• 1 RCA audio input
• 1 1/4” Plug remote control input
• 1 Power input
Physical
• Dimensions: 483x267x89 mm. / 19x10.5x3.5 in.
• Weight: 4.5 Kg. / 9.9 Lbs.
ENGLISH VERSION

TECshow NAVIGATOR 24 XL Specifications

General

Brand	TECshow
Model	NAVIGATOR 24 XL
Category	Controller
Language	English
