1. Power/ Sleep
2. FM/Shortwave Telescopic Antenna
3. LCD Display
4. Light / Snooze Button
5. Tuning Fast/Slow / Lock Button
6. Up / Auto-Scan Button
7. Down / Auto-Scan Button
8. Frequency / Preset Button
9. Page Button
13. SW(SW Meter) Band Button
14. Numeric Keypad
10. Clock Button
11. Alarm Button
12. FM / MW / LW Band &
FM / MW ATS Button
17. Enter / Delete Button
16. Charge On / Off Button
15. Memory / Sys. Set Button
18. Hand Carry Belt
19. FM / SW ANT. Jack
20. ANT. Gain
(DX / Normal / Local)
22. Tone Control
21. Earphone Socket
23. DC 6V Jack
25. Tuning Knob
26. Stand
28. Volume Knob
30. Battery Compartment Cover
27. FM Fine Tuning Knob
24. Reset Button
29. FM Stereo / AM Bandwidth Button
