NT538 ETH
TEMPERATURES channels 1÷8:
Address
LO
(10)
Data HI
Data LO
Note 1
Note 2
R: read
W:write
RW:
read/write
25
2’compl. sign
2’compl. Ch1 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
26
2’compl. sign
2’compl. Ch1 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
27
2’compl. sign
2’compl. Ch1 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
(AL)
RW
28
2’compl. sign
2’compl. Ch1 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
(TRP)
RW
29
2’compl. sign
2’compl. Ch2 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
30
2’compl. sign
2’compl. Ch2 max temperat.
0°C÷ 240°C
0°C÷200°C (*)
R
31
2’compl. sign
2’compl. Ch2 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
RW
32
2’compl. sign
2’compl. Ch2 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
RW
33
2’compl. sign
2’compl. Ch3 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
34
2’compl. sign
2’compl. Ch3 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
35
2’compl. sign
2’compl. Ch3 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
RW
36
2’compl. sign
2’compl. Ch3 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
RW
37
2’compl. sign
2’compl. Ch4 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
38
2’compl. sign
2’compl. Ch4 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
39
2’compl. sign
2’compl. Ch4 temperat.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
RW
40
2’compl. sign
2’compl. Ch4 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
RW
41
2’compl. sign
2’compl. Ch5 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
42
2’compl. sign
2’compl. Ch5 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
43
2’compl. sign
2’compl. Ch5 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
RW
44
2’compl. sign
2’compl. Ch5 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
RW
45
2’compl. sign
2’compl. Ch6 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
46
2’compl. sign
2’compl. Ch6 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
47
2’compl. sign
2’compl. Ch6 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
RW
