TECSYSTEM NT538 ETH - Page 23

23
NT538 ETH
(*) for version –40°C ÷ +200°C
Address LO
(10)
Data HI
Data LO
Note 1
Note 2
R: read
W:write
RW: read/write
57
00
Ch1 Setting
See Note CHx
RW
58
00
Ch2 Setting
See Note CHx
RW
59
00
Ch3 Setting
See Note CHx
RW
60
00
Ch4 Setting
See Note CHx
RW
61
00
Ch5 Setting
See Note CHx
RW
62
00
Ch6 Setting
See Note CHx
RW
63
00
Ch7 Setting
See Note CHx
RW
64
00
Ch8 Setting
See Note CHx
RW
48
2’compl. sign
2’compl. Ch6 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
RW
49
2’compl. sign
2’compl. Ch7 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
50
2’compl. sign
2’compl. Ch7 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
51
2’compl. sign
2’compl. Ch7 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
RW
52
2’compl. sign
2’compl. Ch7 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
RW
53
2’compl. sign
2’compl. Ch8 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
54
2’compl. sign
2’compl. Ch8 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
55
2’compl. sign
2’compl. Ch8 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
RW
56
2’compl. sign
2’compl. Ch8 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
RW
CHANNELs 1÷8: Setting
