TECSYSTEM NT935 User Manual

23
NT935
SERIES
17
00
Address
Modbus address
1÷255
R
18
00
Bdr
Modbus baud
rate
0=2400
1=4800
2=9600
3=19200
4=38400
R
19
00
Parity
Modbus parity
bit
0=N-1
None(1stop)
1=Even
2=Odd
3=N-2
None(2stop)
R
20
00
FREE
See Note
R
TEMPERATURE FANs:
Address
LO
(10)
Data HI
Data LO
Note 1
Note 2
R: read
W:write
RW:
read/write
21
2’compl. sign
Fan_1 ON
1°C ÷ 240°C
1°C ÷ 200°C (*)
RW
22
2’compl. sign
Fan_1 OFF
1° to÷ 240°
1°C ÷ 200°C (*)
RW
23
2’compl. sign
Fan_2 ON
1° to÷ 240°
1°C ÷ 200°C (*)
RW
24
2’compl. sign
Fan_2 OFF
1° to÷ 240°
1°C ÷ 200°C(*)
RW
(*) for version –40°C ÷ +200°C
TEMPERATURES channels 1÷4:
Address
LO
(10)
Data HI
Data LO
Note 1
Note 2
R: read
W:write
RW:
read/write
25
2’compl. sign
2’compl. Ch1 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
26
2’compl. sign
2’compl. Ch1 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R
27
2’compl. sign
2’compl. Ch1 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
(AL)
RW
28
2’compl. sign
2’compl. Ch1 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
(TRP)
RW
29
2’compl. sign
2’compl. Ch2 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
30
2’compl. sign
2’compl. Ch2 max temperat.
0°C÷ 240°C
0°C÷200°C (*)
R
31
2’compl. sign
2’compl. Ch2 temper.
alarm set point
1°C ÷ 240°C
1°C÷200°C (*)
As (AL)
R
32
2’compl. sign
2’compl. Ch2 temper.
trip set point
1°C ÷ 240°C
1°C÷200°C (*)
As (TRP)
R
33
2’compl. sign
2’compl. Ch3 temper.
–10°C ÷ 240°C
–48°C÷200°C (*)
R
34
2’compl. sign
2’compl. Ch3 max temperat.
0°C ÷ 240°C
0°C÷200°C (*)
R

TECSYSTEM NT935 Specifications

General

Brand	TECSYSTEM
Model	NT935
Category	Controller
Language	English
