The following objects are present inside the box:
Control unit
Quick Guide and QR code
2 blocks for panel mounting
1 supply terminal 3 poles pitch 5
Code: 2PL0367- Screws tightening torque 0.5Nm
1 relay terminal 10 poles pitch 5
Code: 2PL0394 -Screws tightening torque 0.5Nm
1 Pt100 sensor terminal 12 poles pitch 3.81
Code: 2PL0420- Screws tightening torque 0,25Nm
1MN0030 REV. 2
ATTENTION: always install the device using the terminals included in the pack. The use of terminals
other than those included with the control unit might cause malfunctions.
