TECSYSTEM t154 User Manual

7
T154
1
2
21
3
20
19
4
18
5
17
16
6
7
15
8
14
13 9
12
11
1MN0101 REV. 0
10
1)
3-digit temperature display
12)
Enter/Reset button
2)
Control unit series
13)
Programming / Setting button
3)
TRIP (red) LED
14)
LED/relay test button
4)
ALARM (yellow) LED
15)
RS (green) LED (not used)
5)
FAULT (red) LED
16)
3-digit channel display
6)
FAN 1 (yellow) LED
17)
T-max mode selection (red) LED
7)
FAN 2 (yellow) LED (not used)
18)
Man mode selection (yellow) LED
8)
Display mode selection button
19)
Auto mode selection (green) LED
9)
Fixing block
20)
Scan mode selection (yellow) LED
10)
UP key
21)
Fixing block
11)
DOWN key
FRONT PANEL
