TECSYSTEM t154 User Manual

5
T154
TECHNICAL SPECIFICATIONS
T154
POWER SUPPLY
Supply rated values
24-240 Vac-Vdc
50/60Hz
Maximum and minimum supply values
20-270 Vac-Vdc
50/60Hz
Vdc with reversible polarities
●
INPUTS
4 inputs for RTD sensors, Pt100 type with 3 wires (max section 1.5mm²)
●
Connections on removable terminal strips
●
Input channels protected against electromagnetic interference
●
Cable compensation for thermistors
500 m (1 mm²)
OUTPUTS
2 alarm relays (ALARM AND TRIP) SPDT
●
1 sensor or operating failure (FAULT) relay SPST
●
1 ventilation management relays SPST FAN 1
●
Output relay with 10A-250Vac-res COSФ=1 contacts.
●
DIMENSIONS
100x100 mm– din43700-depth 131mm (terminal block included)
Hole 92 x 92 mm
TESTS AND PERFORMANCE
Construction in compliance with CE regulations
●
Protection from electrical interference EN 61000-4-4
●
Dielectric strength 1500 Vac for a min. between output relays and sensors, relays and power supply, power
supply and sensors
●
Accuracy ±1% full scale value, ±1 digit
●
Ambient operating temperature from –20°C to +60°C
●
Humidity 90% non-condensing
●
