• It is advised to stay out of the direct airstream.
• Never drink the drain water from the airconditioner.
B PART NAMES
INDOOR UNIT Indoor unit
a Front panel
b Air inlet
c Air filter (behind front panel)
d Air outlet
e Horizontal air flow grille
f Vertical air flow louver
g Display panel
h Remote controller signal receiver
i Remote controller (see chapter E for
more details and operation)
j Manual control button (auto/cool)
OUTDOOR UNIT Outdoor unit
k Connecting pipe, drain hose (not inclu-
ded)
l Air inlet (side and rear)
m Air outlet
The operation indicator lights flash rapidly (five times per second) when safety protection features come
into operation.
G
NOTE!
All the pictures in this manual and on the gift box are for explanation and indication purpose
only. They may be slightly different from the air conditioner you purchased. The actual shape
shall prevail.
4
3
5
2
6
1
10
9
12
13
11
7
8
G
ATTENTION!
• Never use the device with a damaged power cord, plug, cabinet or
control panel.
• Failing to follow the instructions may lead to nullification of the
guarantee on this device.
