teel 4P847A - Performance Chart

2
Teel Operating Instructions and Parts Manual
4P847A thru 4P851A, 4P852 thru 4P865, 4RH01 thru 4RH06,
4RG76 thru 4RG84, 4RG94 thru 4RG97 and 4RG99
Teel Deep Well Submersible Pumps
®
E
N
G
L
I
S
H
Performance Chart
4P847A 20 * * 5.7 5.3 5.0 4.7 4.2 2.3 – – – – – 4P834
4P848A 30 5.7 5.5 5.3 5.0 4.7 4.2 3.7 1.7 – – – – – 4RK68
40 5.5 5.2 4.8 4.5 4.2 3.7 3.0 – – – – – –
50 5.0 4.8 4.5 4.2 3.7 3.0 2.3 – – – – – –
60 4.8 4.5 4.0 3.7 3.0 2.3 1.3 – – – – – –
4P849A 20 * * * 7.4 7.3 7.0 6.7 5.7 4.5 2.8 – – – 4P835
4P850A 30 * * 7.4 7.2 7.1 6.8 6.3 5.2 3.6 1.5 – – – 4P836
4RG99 40 * 7.4 7.2 7.0 6.8 6.4 5.8 4.6 2.9 – – – – 4RK68
4RH03 50 7.3 7.2 7.0 6.7 6.4 5.9 5.3 3.7 1.7 – – – –
4RH04 60 7.2 6.9 6.7 6.3 5.9 5.3 4.7 3.0 – – – – –
4P851A 20 * * * * * 7.4 7.3 6.9 6.5 5.7 4.8 3.5 – 4P835
4RH01 30 * * * * 7.4 7.3 7.1 6.7 6.1 5.3 4.2 3.0 – 4P836
4RH05 40 * * * 7.4 7.3 7.2 7.0 6.5 5.7 4.9 3.6 2.4 – 4RK68
50 * * 7.4 7.3 7.2 7.0 6.8 6.2 5.4 4.3 3.1 1.3 –
60 7.5 7.4 7.3 7.1 7.0 6.8 6.5 5.8 4.9 3.6 2.4 – –
4RH02 20 * * * * * * 7.5 7.2 7.0 6.6 6.0 5.3 3.5 4P835
4RH06 30 * * * * * 7.5 7.4 7.2 6.9 6.3 5.8 5.1 3.1 4P836
40 * * * * 7.5 7.4 7.3 7.0 6.7 6.1 5.4 4.6 2.6 4RK68
50 * * * 7.5 7.4 7.3 7.2 6.9 6.4 5.8 5.1 4.1 1.9
60 * * 7.5 7.4 7.3 7.2 7.0 6.7 6.1 5.5 4.7 3.6 0.7
5 GPM Series Pumps For Low Capacity Wells
Model Tank Gallons Per Minute at Vertical Depth To Water (Not Pump Setting Depth)
Suggested
No. PSI 20’ 40’ 60’ 80’ 100’ 125’ 150’ 200’ 250’ 300’ 350’ 400’ 500’ Tank**
4P852 20 11.0 11.0 10.0 8.0 5.0 – – – – – – – – 4P837
4P853 30 11.0 9.7 7.9 4.7 – – – – – – – – – 4RK69
4P854 40 9.5 7.5 4.3 – – – – – – – – – –
50 7.2 3.8 – – – – – – – – – – –
60 3.7 – – – – – – – – – – – –
4P855 20 15.6 14.8 14.0 13.0 11.8 10.2 8.2 2.1 – – – – – 4P837
4P856 30 14.6 13.7 12.8 11.6 10.3 8.3 6.0 – – – – – – 4RK69
4P857 40 13.6 12.6 11.5 10.1 8.6 6.1 2.8 – – – – – –
4P858 50 12.5 11.3 9.9 8.2 6.2 3.0 – – – – – – –
4RG76 60 11.0 9.6 8.0 6.0 3.2 – – – – – – – –
4RG80
4RG81
4P859 20 * 15.8 15.0 14.4 13.7 12.8 11.7 9.2 5.7 – – – – 4P838
4P860 30 15.5 15.0 14.3 13.5 12.8 11.8 10.6 7.7 3.5 – – – – 4RK72
4RG77 40 14.9 14.2 13.5 12.7 11.9 10.7 9.4 6.0 – – – – – 4RK73
4RG82 50 14.1 13.4 12.5 11.7 10.8 9.4 8.0 4.1 – – – – –
60 13.2 12.4 11.6 10.6 9.5 8.1 6.3 – – – – – –
4P861 20 * * 15.7 15.3 14.8 14.2 13.4 11.8 9.8 7.2 3.8 – – 4P838
4RG78 30 * 15.6 15.2 14.7 14.2 13.5 12.8 10.8 8.5 5.8 2.0 – – 4RK72
4RG83 40 15.6 15.1 14.6 14.1 13.5 12.9 11.9 9.8 7.4 4.2 – – – 4RK73
50 15.1 14.5 14.0 13.4 12.9 11.9 10.9 8.8 5.9 2.2 – – –
60 14.4 13.9 13.3 12.8 12.0 11.0 10.0 7.5 4.5 – – – –
4P862 20 * * * * 15.8 15.4 14.9 14.9 12.8 11.6 10.3 8.7 4.4 4P838
4RG79 30 * * * 15.7 15.4 14.9 14.5 13.4 12.3 11.0 9.6 7.9 2.9 4RK72
4RG84 40 * 16.0 15.6 15.3 15.0 14.5 14.0 12.9 11.7 10.4 8.9 7.1 1.0 4RK73
50 15.9 15.5 15.3 14.9 14.5 14.0 13.5 12.4 11.0 9.7 8.0 6.0 –
60 15.5 15.2 14.8 14.4 14.0 13.5 13.0 11.7 10.5 9.0 7.3 4.7 –
10 GPM Series Pumps For Average Capacity Wells
Model Tank Gallons Per Minute at Vertical Depth To Water (Not Pump Setting Depth)
Suggested
No. PSI 20’ 40’ 60’ 80’ 100’ 125’ 150’ 200’ 250’ 300’ 350’ 400’ 500’ Tank**
(*) Do not operate pump at this setting; motor will overload and may fail.
(**) Suggested tanks are sized to provide drawdown sufficient to allow approximately 2 minute cycles at 80 ft.
depth to water. For shallower wells, use next size larger tank.
