4
Teel Operating Instructions and Parts Manual
4RJ47, 4RJ48, 4RJ49, 4RJ50, 4P035A and 4P036A
Teel Heavy Duty Cast Iron
Convertible Jet Pumps
®
E
N
G
L
I
S
H
TABLE V 4” DOUBLE PIPE DEEP WELL PERFORMANCE AND EJECTOR CHART – EJECTOR PACKAGE 2P430A
Feet to Pressure in psi Pressure in psi
Water 20 30 40 50 20 30 40 50
GPH w/J32P-33 Venturi & #55 Nozzle GPH w/J32P-33 Venturi & #55 Nozzle
30’ 1320 1060 815 580 1490 1200 925 660
40 1160 910 670 440 1310 1030 760 500
50 1030 800 590 385 1160 900 640 400
GPH w/J32P-29 Venturi & #51 Nozzle GPH w/J32P-29 Venturi & #55 Nozzle
60 600 480 370 260 710 620 510 360
70 525 420 320 230 640 565 450 310
80 465 370 285 200 550 470 355 215
GPH w/J32P-22 Venturi & #53 Nozzle GPH w/J32P-22 Venturi & #54 Nozzle
90 320 250 190 135 400 345 290 230
100 280 225 170 120 350 300 250 190
110 250 200 155 110 310 265 215 160
Model 4P035A Model 4P036A
1 HP 1
1
⁄2 HP
NOTE: psi = Pounds per square inch (pressure).
TABLE IV SHALLOW WELL PERFORMANCE AND EJECTOR CHART – EJECTOR PACKAGE 2P429A
Feet to Pressure in psi Pressure in psi
Water 20 30 40 50 20 30 40 50
GPH w/N32P-75B Venturi & #57 Nozzle GPH w/N32P-69B Venturi & #55 Nozzle
5’ 1020 1010 975 910 1340 1320 1295 1130
10 910 890 870 830 1200 1190 1180 1130
15 780 760 745 720 1025 1015 995 970
20 650 625 605 575 855 845 835 820
25 470 455 445 425 615 600 590 575
Model 4P035A Model 4P036A
1 HP 1
1
⁄2 HP
Performance Chart (Continued)
